NORCO SIGHT A2 29" / 27.5" BIKE

Description

NORCO SIGHT A2 29" / 27.5" BIKE

  • Discipline: All-Mountain
  • Travel: Front 170mm / Rear 160mm
  • Wheel Size: Mixed
  • ColourRust Red

The Sight 160 is next level - big travel, big spec, and ready for big mountain riding. Whether you’re out racing an enduro or love going fast on technical trails, this is your bike to blow through the chunder. Inspired by the gnarliest trails in the backwoods of BC, built for riders living in areas where the terrain demands more out of the bike they ride.

HIGHLIGHTS



  • Sight 160 Aluminum frame
  • RockShox Zeb Select Charger 170mm fork
  • RockShox Vivid Coil Select+ shock & Sprindex Spring
  • Shimano Deore drivetrain
  • Shimano Deore brakes
  • Proprietary chain guide and idler design
  • OneUp EDC tool
  • Compatible with Missing Link Kit for wheel size conversion
  • Weight: 18kg (39.68lbs)

Balanced weight distribution for top-of-class ride feel across sizes.

Stabilised rear centres with proportional rear ends, and seat tube angles that steepen from S1 to S5, ensure consistent rider weight distribution. Shorter seat tubes with long dropper posts keep the saddle out of the way on technical descents the Sight is known for.

170mm/160mm travel for BC-inspired trails.

We've taken the confidence-inspiring stability of a Sight and made it more. Supported up front with a 170mm fork and in the rear with a longer 65mm stroke shock for 160mm; giving the Sight all you need for attacking tech and rougher, BC-inspired trails..

ENDURO GEOMETRY

Downhill oriented geometry, with efficient pedaling.

Sight 160 features a slacker headtube angle and a slightly taller bottom bracket than our standard Sight geometry to accommodate all the G's you push and obstacles you roll.

SPECIFICATION

FRAME ALUMINUM FRAME, 160MM TRAVEL, UDH, HANGERLESS INTERFACE COMPATIBLE, RIDE ALIGNEDTM
FORK ROCKSHOX ZEB SELECT CHARGER RC, 170MM TRAVEL, 44MM O!SET, FENDER INCLUDED
REAR SHOCK ROCKSHOX VIVID COIL SELECT+, 205X65MM TR, SPRINDEX SPRING
HEADSET FSA NO. 57 ZS, SEALED BEARING, TAPERED 1-1/8" - 1.5", ( ZS44/28.6 | ZS56/40 )
GRIPS WTB WAFFLE, 140MM LENGTH
HANDLE BAR NORCO 6061 DB ALLOY, 760MM - 20MM RISE (S1), 780MM - 20MM RISE (S2), 800MM- 30MM RISE (S3, S4, S5)
STEM 6060 ALLOY, 40MM LENGTH, 35MM CLAMP
SEAT POST TRANZX YSI160 RAD+, 34.9MM, 150 (S1) -170MM (S2) -200MM (S3, S4) -230MM (S5)
SEAT POST CLAMP NORCO ALLOY NUTTED CLAMP
SADDLE WTB VOLT MED, 142X265 MM, STEEL RAILS
FRONT BRAKE SHIMANO DEORE MT520 4-P, METALLIC PADS
FRONT BRAKE ROTOR SHIMANO RT-64, 203MM, C-LOCK
REAR BRAKE SHIMANO DEORE MT520 4-P, METALLIC PADS
REAR BRAKE ROTOR SHIMANO RT-64, 180MM, C-LOCK
BRAKE LEVERS SHIMANO DEORE MT5201
SHIFTER REAR SHIMANO DEORE SL-M6100-R, 12SP
REAR DERAILLEUR SHIMANO DEORE RD-M6100, SGS, 12SP
CASSETTE SHIMANO DEORE CS-M6100-12, 10-51T, 12SP
CHAIN SHIMANO DEORE CN-M6100, 12SPD
CRANKSET SHIMANO DEORE FC-MT6120-1, 32T, CL55, 165MM (S1, S2) -170MM (S3, S4, S5)
BOTTOM BRACKET SHIMANO, BSA 73MM
FRONT HUB SHIMANO HB-MTC500-15-B, 15X110MM BOOST, 32H, C-LOCK
REAR HUB SHIMANO FH-TC500-MS-B, 12 X 148MM BOOST, MICRO SPLINE, 32H, C-LOCK
SPOKES/NIPPLES SAPIM RACE BUTTED 2.0/1.8/2.0 14G BLACK STAINLESS STEEL
RIMS WTB ST TOUGH I30 TCS 2.0, 32H, 29"-27.5" F/R, 30MM ID
FRONT TYRE MAXXIS ASSEGAI, 3C MAXXGRIP NEW EXO+, 29" X 2.5", FOLDING
REAR TYRE MAXXIS MINION DHR II, 3C MAXX GRIP DD, 27.5" X 2.4", FOLDING

Please note: Specifications are subject to change without notice.

GEOMETRY

All measurements are shown in millimetres.


SIZE 1 SIZE 2 SIZE 3 SIZE 4 SIZE 5
WHEEL SIZE 29"/27.5"
TRAVEL (MM FRONT / MM REAR) 170/160MM
REACH 416 441 466 491 516
STACK 622 631 640 650 659
HTA HEAD TUBE ANGLE 63.5
OS FORK OFFSET 44
ST SEAT TUBE LENGTH 350 370 385 430  445
STA EFFECTIVE SEAT TUBE ANGLE 76.25 76.5 77 77.25 77.50
RC REAR CENTRE LENGTH 426 430 434 438 442
BB BOTTOM BRACKET DROP 20.5/20.5
BBH BOTTOM BRACKET HEIGHT 353
HTT HORIZONTAL TOP TUBE 567 591 615 639 663
WB WHEELBASE 1192 1225 1259 1292 1326
SOH STANDOVER 671 685 694 715 725
HT HEAD TUBE LENGTH 105 115 125 135 145
TRAIL 140
RECOMMENDED SEATPOST DROP 150 170 200 200 230
MAXIMUM POST INSERTION 250 270 300 300 330
STEM LENGTH 40
CRANK LENGTH 170
TYRE SIZE 2.35" - 2.6"
WATER BOTTLE COMPATIBLE 1 X 750ML

SIZE GUIDE
